DS-2CE10HFT-F Hikvision

Hikvision 5mp colorvu camera

Camera

• Image Sensor                      5 MP CMOS

• Max. Resolution                   2560 (H) × 1944 (V)

• Illumination                          0.0005 Lux @ (F1.0, AGC ON), 0 Lux with White Light

• Shutter Time                        PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
• Day & Night                         Color
• Angle Adjustment                Pan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°
• Signal System                      PAL/NTSC

Lens

• Lens Type                             3.6 mm, 6 mm fixed lens
• Focal Length & FOV             80.1° (3.6 mm), 49.3° (6 mm)
• Lens Mount                          M16

• Image
• Image Parameters Switch    STD/HIGH-SAT
• Image Settings                     Brightness, Sharpness, Mirror, Smart Light
• Frame Rate

TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080p@30fps, 1080p@25fps CVI: 4MP@30fps, 4MP@25fps                                                           AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC

• Day/Night Mode                  Color
• Wide Dynamic Range (WDR)≥130 dB
• Image Enhancement           BLC, HLC
• White Balance                      Auto/Manual
• White Light                          Auto/Off
• AGC                                      Yes

• Interface
• Video Output                     Switchable TVI/AHD/CVI/CVBS

General

• MaterialMetal
• Dimension                            68 mm × 70 mm × 168.2 mm (2.68″ × 2.76″ × 6.62″)
• Weight                                 Approx. 350 g (0.77 lb.)
• Operating Condition          ‘-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
• Communication                   HIKVISION-C
• LanguageEnglish
• Power Supply                       12 VDC ± 25%

*You are recommended to use one power adapter to supply the power for one camera.

• ConsumptionMax.              3.5 W
• White Light Range             Up to 20m

• Approval
• Protection                          IP67

HIKVISION 4 channel DVR

Recording

• Video Compression                 H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
• Encoding Resolution               When 1080p Lite mode is not enabled: ,4 MP                                                                                                                                                        lite/3P/1080p/720p/VGA/WD1/4CIF/CIF;,When 1080p Lite mode is enabled: ,4 MP ite/3 MP/1080p lite/720p                                                      lite/VGA/WD1/4CIF/CIF
• Frame Rate                              Main stream:,When 1080p Lite mode not enabled: ,For 4 MP stream access:,4 MP lite@15fps; 1080p                                                               lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) ,For 3 MP stream access: 3                                                                                                   MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps,For 1080p stream access: ,1080p/720p@15fps;                                                                             VGA/WD1/4CIF/CIF@25fps (P)/30fps (N),For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps                                                               (P)/30fps (N),When 1080p Lite mode enabled: ,4 MP lite/3 MP@15fps; 1080p lite/720p                                                                                        lite/VGA/WD1/4CIF/CIF@25fps ,(P)/30fps (N),Sub-stream: ,WD1/4CIF@12fps; CIF@25fps (P)/30fps (N),
• Video Bit Rate                         32 Kbps to 6 Mbps
• Dual Stream                            Support
• Stream Type                           Video, Video & Audio
• Audio Compression               G.711u
• Audio Bit Rate                        64 Kbps

Video And Audio

• IP Video Input                         2-ch (up to 6-ch) Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
• Analog Video Input                4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
• AHD Input                               4 MP, 1080p25, 1080p30, 720p25, 720p30
• HDCVI Input                           1080p25, 1080p30, 720p25, 720p30
• CVBS Input                             Support
• Audio Input                             1-ch, RCA (2.0 Vp-p, 1 KΩ)
• Audio Output                         1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio                      1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
• Synchronous Playback         4-ch
• HDTVI Input                            4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60,*: The 3 MP signal input is only available                                                   for channel 1 of DS-7104HQHI-K1, channel 1/2 of DS-7108HQHI-K1, and channel 1/2/3/4 of DS-7116HQHI-K1.
• VGA/HDMI Output                 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Network

• Remote Connections           32
• Network Protocols               TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
• Network Interface                 1, RJ45 10M/100M self-adaptive Ethernet interface

Auxiliary Interface

• SATA                                     1 SATA interface
• Capacity                               Up to 6 TB capacity for each disk
• Alarm In/OutN/A
• USB Interface                       Real panel: 2 × USB 2.0

General

• Power Supply                               12 VDC
• Consumption (Without HDD)      ≤ 8 W
• Working Temperature                 -10 °C to +55 °C (+14 °F to +131 °F)
• Working Humidity                       10% to 90%
• Dimensions (W × D × H)              200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
• Weights (Without HDD)               ≤ 1 kg (2.2 lb)
