Ezviz EL3 License Plate Recognition LPR AI-Powered Human Vehicle Shape Detection Camera

EL3 2

Introducing the EZVIZ EL3, an innovative blend of an advanced security camera and a smartly adjustable wall light that’s ready to upgrade your backyard, garage or front door. When the daylight turns into moonlight, the EL3 can create pleasant ambient lighting at your preference, while protecting your property with AI-powered detection capability – it alerts you about moving people and vehicles in your detection zones, and recognizes license plate in case someone parks in your private area.

EL3 3 EL3 4A EL3 5 EL3 6

See wider and clearer, with extended vision

EL3 7

Reviews

There are no reviews yet.

Be the first to review “Ezviz EL3 License Plate Recognition LPR AI-Powered Human Vehicle Shape Detection Camera”

Specifications
Model	CS-H6c-R105-1L3WF
Camera
Image Sensor	1/2.7″ Progressive Scan CMOS
Shutter Speed	Self-adaptive shutter
Lens	4mm @ F1.6, viewing angle: 82° (Horizontal), 48° (Vertical), 98° (Diagonal)
Lens Mount	M12
Day & Night	IR-cut filter with auto-switching
DNR	3D DNR
WDR	Digital WDR
Compression
Video Compression	H.264/H.265
Video Bit Rate	Adaptive bit rate.
Max. Resolution	2304 × 1296
Frame Rate	Self-Adaptive during network transmission
Network
Smart Alarm	Motion Detection, Human Shape Detection, Loud Noise Detection
Wi-Fi Pairing	AP paring
Protocol	EZVIZ Cloud Proprietary Protocol
Interface Protocol	EZVIZ Cloud Proprietary Protocol
Interface
Storage	Supports microSD card (Up to 512 G)
Power	TYPE-C
Wired Network	RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard	IEEE802.11b, 802.11g, 802.11n
Frequency Range	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	Supports 20MHz
Security	WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate	11b: 11Mbps, 11g :54Mbps, 11n :72Mbps
Output Power(EIRP)	19 dBm
Antenna Gain	1.9 dBi
General
Operating Conditions	-10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)
Power Supply	DC 5V/1A
Power Consumption	5W max
IR Range	MAX. 10 meters (33ft)
Dimensions	88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”)
Packaging Dimensions	103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”)
Bare Weight	218g (0.48lb)
In the box
In the box	– Camera
	– Power Adapter
	– Power Cable
	– Drill Template
	– Mounting Plate
	– EZVIZ Screw Kit
	– Regulatory Information
	– Quick Start Guide
Certifications
Certifications	CE / UL / WEEE / REACH / RoHS
